100kHz-3MHz 50W Medium Long Wave HF RF Wideband Power Amplifier AMP
100K-MPLF-ZK2MXY
Delivery
DHL express - Fast
Delivery time varies by country
from 3 EUR
FedEx express - Reliable international shipping
Delivery time varies by country
from 3 EUR
We offer free shipping for orders over 415 EUR. Free shipping also applies to products marked with the Free Shipping sticker, even if the order total is below this amount. Availability and delivery times may vary depending on your country.
Payment options
Explore and use a variety of other convenient payment methods available at the checkout page.
Our advantages
- Order Protection: If your order is lost, we guarantee a replacement or a refund. Terms apply.
- Easy Returns: Enjoy a simple and hassle-free return process.
- Flexible Payments: Choose from multiple secure payment options that fit your needs.
- Best Prices: Get the best value on all our products.
Description
The 100kHz-3MHz 50W RF Power Amplifier is a linear, low-distortion amplifier designed for medium/long wave and HF applications. With 50W output and 47dB gain, it boosts signals for TPMS, wireless charging, remote controls, research, and amateur radio projects.
Key Specifications
- Frequency Range: 100kHz – 3MHz
- Output Power: 50W
- Gain: ~47dB (0dBm input → 50W output)
- Power Supply: 48V DC (single voltage)
- Impedance: 50Ω (input/output)
- Connectors: SMA female
- Dimensions: 103×90×83mm
Applications
- TPMS (Tire Pressure Monitoring System) signal boosting
- Wireless charging communication enhancement
- Remote control system power stages
- Educational labs and research (universities/institutes)
- Amateur radio and long-wave transmission
