SDR 3980 USRP | 8 TX/RX Channels, ADRV-9009 ×4, 75 MHz – 6 GHz, 450 MHz Tx BW, i9 CPU
We offer free shipping for orders over 415 EUR. Free shipping also applies to products marked with the Free Shipping sticker, even if the order total is below this amount. Availability and delivery times may vary depending on your country.
- Order Protection: If your order is lost, we guarantee a replacement or a refund. Terms apply.
- Easy Returns: Enjoy a simple and hassle-free return process.
- Flexible Payments: Choose from multiple secure payment options that fit your needs.
- Best Prices: Get the best value on all our products.
SDR 3980 is a standalone, high-performance 8-channel Software Defined Radio (SDR) device equipped with 4× ADRV-9009 RF chips and an onboard Intel i9-9900K processor. Covering a frequency range of 75 MHz to 6 GHz, this platform delivers 450 MHz transmit and 200 MHz receive bandwidth, ideal for advanced wireless research and development.
Powered by a Xilinx Zynq UltraScale+ ZU11EG FPGA and running a built-in Ubuntu OS with GNU Radio support, it enables seamless prototyping and signal processing. The system also features:
- 8× TX and 8× RX channels
- 8× PCIe Gen3 interfaces, 1× SFP+ 10Gbps
- 64 GB DDR4 RAM and 500 GB SSD
- Integrated APU, RPU, GPU for real-time control and processing
- Multi-chip phase synchronization support
- Size: 42 × 28 × 17.5 cm | Weight: 9.4 kg
This SDR is ideal for applications such as 5G NR simulation, 802.11 protocol emulation, beamforming, cognitive radio, RF sensing, and MIMO system development.
