USRP N310 SDR | 4x4 MIMO, 10–6GHz, 100MHz BW, AD9371, Zynq-7100, SFP+
We offer free shipping for orders over 415 EUR. Free shipping also applies to products marked with the Free Shipping sticker, even if the order total is below this amount. Availability and delivery times may vary depending on your country.
- Order Protection: If your order is lost, we guarantee a replacement or a refund. Terms apply.
- Easy Returns: Enjoy a simple and hassle-free return process.
- Flexible Payments: Choose from multiple secure payment options that fit your needs.
- Best Prices: Get the best value on all our products.
The USRP N310 is a networked Software Defined Radio (SDR) platform engineered for large-scale, distributed, and high-reliability wireless systems. Featuring four independent TX/RX channels with dual AD9371 RFICs, it delivers up to 100 MHz bandwidth per channel over a frequency range of 10 MHz to 6 GHz. The compact half-width RU design makes it one of the highest channel density SDRs available.
Key Features and Specifications
- 4 TX/RX channels (4x4 MIMO, independent tuning pairs)
- Frequency range: 10 MHz – 6 GHz
- Bandwidth: 100 MHz per channel
- AD9371 RF front end, high dynamic range
- Xilinx Zynq-7100 SoC FPGA with dual-core ARM CPU
- Sampling rates: 122.88, 125, 153.6 MSps
- ADC: 16 bits, DAC: 14 bits
- Dual SFP+ ports: 1 GbE, 10 GbE, Aurora
- Remote management: software updates, reboot, self-test, monitoring
- GPSDO option for high-precision timing (0.1 ppm, <8ns UTC accuracy)
- Output power: up to 20 dBm; gain range: up to 75 dB
- Operating temperature: 0–50°C; Size: 42.5 × 22 × 4.5 cm; Weight: 3.8 kg
Software Compatibility
Fully compatible with GNU Radio, USRP Hardware Driver (UHD), and the RFNoC FPGA development framework. Supports embedded Linux for standalone operation and high-speed streaming to host PCs or coprocessors.
Applications
- Wireless testbeds and research
- Distributed and remote radio heads
- Spectrum monitoring and analysis
- Large-scale MIMO and multi-channel systems
- 5G prototyping, IoT, and academic research
