The ANTSDR U220 is a compact USB3.0 Software Defined Radio (SDR) transceiver featuring the ADI AD9361/AD9363 RFIC in a 2×2 MIMO configuration. It covers 70 MHz to 6 GHz with up to 56 MHz instantaneous bandwidth per channel and connects via high-speed USB 3.0 for real-time data...

The MicroPhase A7-Lite is a versatile Artix-7 FPGA demo board available in three densities: XC7A35T, XC7A100T, and XC7A200T. Each model features abundant logic cells, DSP slices, Block RAM, and a 4 Gbit DDR3 interface, packaged in a compact 80 × 56 mm form factor. Key Features and...

The Microphase Z7-Nano is a compact FPGA development board featuring the Xilinx Zynq-7000 SoC in two variants: Z7-Nano 7010 (XC7Z010CLG400-1) with 28K logic cells and 667 MHz dual-core Cortex-A9, or Z7-Nano 7020 (XC7Z020CLG400-2) with 85K logic cells and 766 MHz dual-core Cortex-A9....

The MicroPhase ANTSDR E316 is a portable 2×2 MIMO Software Defined Radio (SDR) demo board based on the ADI AD9361/AD9363 RFIC and Xilinx Zynq-7020 SoC . It covers 70 MHz–6 GHz with up to 56 MHz instantaneous bandwidth , and features 1 GB DDR3, 256 Mb QSPI flash, Gigabit Ethernet,...

The MicroPhase Mizar Zynq-7000 FPGA Development Board is available in two variants: 7010 (XC7Z010CLG400-1) with 28K logic cells and 667 MHz dual-core Cortex-A9, or 7020 (XC7Z020CLG400-2) with 85K cells and 766 MHz. It features 4 Gbit DDR3, 8 Gbit optional DDR3, and 256 Mbit QSPI flash...

The Microphase PE300 FPGA Development Kit features the XME0712 core family with three Artix-7 variants— XC7A35T (33K cells), XC7A75T (75K cells), and XC7A200T (215K cells). Each module plugs into the PE300 baseboard, offering 1 GB DDR3, PCIe 2.0×4, and industrial temperature operation...

The MicroPhase ANTSDR U200 is a compact 1×1 SDR transceiver board powered by the ADI AD9363 RFIC . It covers 325 MHz–3.8 GHz  with up to 56 MHz instantaneous bandwidth and delivers transmit power up to 10 dBm with a noise figure <8 dB. Key Features and Specifications...

The MicroPhase Z7-Lite is a compact FPGA development board powered by the Xilinx Zynq-7000 SoC , offered in two variants: Z7-Lite 7010 (XC7Z010, 28 K logic cells, 667 MHz dual-core Cortex-A9) or Z7-Lite 7020 (XC7Z020, 85 K cells, 766 MHz dual-core Cortex-A9). Key Features and...

The MicroPhase XME7100 is an industrial-grade Xilinx Zynq-7000 FPGA core board available with either the XC7Z035-2FFG676I (275K logic cells) or the XC7Z100-2FFG9001 (444K logic cells) module, delivering up to 2,020 DSP slices and 16 GTX transceiver channels , with PCIe 2.0×8 host...
